1. Standard : ISO /DIN /ANSI
2. Model : 25-1; 35-1; 40-1; 50-1; 60-1; 80-1; 100-1; 120-1; 140-1; 160-1; 180-1; 200-1; 240-1;
04B-1; 05B-1; 06B-1; 08B-1; 10B-1; 12B-1; 16B-1; 20B-1; 24B-1; 28B-1; 32B-1;
Duplex, Triplex, Heavy duty etc.
3.Materials : Alloy Steel & Stainless Steel
Transmission Roller Chain:
1.All parts are heat treatment(quenching and tempering) and controlled in a reasonable tolerance range.
2.Tensile strength:15-20% higher than the standard
3.Certificate of Quality: ISO 9001:2000,SGS
4.Centreless grinding.
5.Good lubrication with excellent grease.
6.Color:self,dark yellow,dark blue,black
Techncial DateChain | Pitch | Roller | Width | Pin | Pin | Inner | Plate | Breaking | |
N0. | diameter | between | diameter | length | plate | thickness | Load | ||
inner plates | depth | ||||||||
P | d1 | b1 | d2 | L | Lc | h2 | t/T | Q | |
max | min | max | max | max | max | max | |||
mm | mm | mm | mm | mm | mm | mm | mm | kN | |
*25SS | 6.35 | 3.3 | 3.18 | 2.31 | 7.9 | 8.4 | 6 | 0.8 | 2.5/568 |
*35SS | 9.525 | 5.08 | 4.77 | 3.58 | 12.4 | 13.17 | 9.00 | 1.30 | 5.5/1250 |
40SS | 12.700 | 7.95 | 7.85 | 3.96 | 16.6 | 17.8 | 12.00 | 1.50 | 9.6/2182 |
41SS | 12.700 | 7.77 | 6.25 | 3.58 | 13.75 | 15.0 | 9.91 | 1.30 | 6.0/1360 |
50SS | 15.875 | 10.16 | 9.40 | 5.08 | 20.7 | 22.2 | 15.09 | 2.03 | 15.2/3455 |
60SS | 19.050 | 11.91 | 12.57 | 5.94 | 25.9 | 27.7 | 18.00 | 2.42 | 21.7/4932 |
80SS | 25.4 | 15.88 | 15.75 | 7.92 | 32.7 | 35.0 | 24.00 | 3.25 | 38.9/8841 |
100SS | 31.750 | 19.05 | 18.90 | 9.53 | 40.4 | 44.7 | 30.00 | 4.00 | 60.0/13636 |
120SS | 38.100 | 22.23 | 25.22 | 11.10 | 50.3 | 54.3 | 35.70 | 4.80 | 72.5/16477 |
140SS | 44.450 | 25.40 | 25.22 | 12.70 | 54.4 | 59.0 | 41.0 | 5.60 | 94.0/21363 |
04BSS | 6.000 | 4.00 | 2.80 | 1.85 | 6.8 | 7.8 | 5 | 0.6 | 2.0/455 |
05BSS | 8.000 | 5.00 | 3.00 | 2.31 | 8.20 | 8.9 | 7.10 | 0.80 | 3.5/795 |
#06BSS | 9.525 | 6.35 | 5.72 | 3.28 | 13.15 | 14.1 | 8.20 | 1.30 | 6.2/1409 |
08BSS | 12.700 | 8.51 | 7.75 | 4.45 | 16.7 | 18.2 | 11.80 | 1.0 | 12.0/2727 |
10BSS | 15.875 | 10.16 | 9.65 | 5.08 | 19.5 | 20.9 | 14.70 | 1.70 | 14.5/3295 |
12BSS | 19.050 | 12.07 | 11.68 | 5.72 | 22.5 | 24.2 | 16.00 | 1.85 | 18.5/4205 |
16BSS | 25.400 | 15.88 | 17.02 | 8.28 | 36.1 | 37.4 | 21.00 | 4.15/3.1 | 40.0/9091 |
20BSS | 31.750 | 19.05 | 19.56 | 10.19 | 41.3 | 45.0 | 26.40 | 4.5/3..5 | 59.0/13409 |
24BSS | 38.1 | 25.4 | 25.40 | 14.63 | 53.4 | 57.8 | 33.20 | 6.0/4.8 | 104.0/25454 |
32BSS | 50.800 | 29.21 | 30.99 | 17.81 | 66.0 | 71.0 | 42.00 | 7.0/6.0 | 150.0/34090 |
Stainless Steel Roller Chain Top Roller Chain with Nylon Material Top Roller Chain with Steel Maatrial Extend Pin Roller Chian
Manufacturing
Application
About Us
Kasin group was established in 1989, and its first product is casting carrier trolley for power & free conveyor system. In 1995, Kasin purchased Luoyang Guoping Forging Factory (LYGP), a marketer of forging bolts & nuts to power & free line market in china. With this acquisition, Kasin positioned itself as one of major parts suppliers of monorail and power & free conveyor system in china.
In 2005, H&H Corp., a professional manufacturer of large size conveyor chain, was purchased a portion as sharehould by Kasin, and worked as export window to all over the world, especially bucket elevator chain, sugar mill chain, welded mill scaper chain.
In 2015, Kasin established itself machinery company/Kasin machinery(Henan)Co.,Ltd., produced fleixible coupling, eg: FCL Coupling, NM Coupling, Curved Jaw Coupling, Chain Coupling andJaw Coupling.
Nowadays,Kasin is one of the biggest professional specialist of Engineering Class Conveyor Chain, Drop Forged Rivetless Chain, Forged Chain, Sugar Mill Chain, Bucket Elevator Chain, Flexible Couplings and 100% to oversea market, covering Japan, U.S. and Europ etc.
With the certificate of ISO 9001 and GB/T 19001, Kasin provide top quality products at the reasonable price, to win-win situation in long-terms cooperation, adhering to the slogan: "FIRST TIME, EVERY TIME".
Our mission is to provide highest quality products at the best possible price. And in doing so, to provide an unmatched customer experience and to build customer trust and satisfaction. Honest, Quality, Efficient, Developing, Security the five crucial components constituting KASIN, which is the key motto for all of the KASIN employees. Therefore, we keep striving to build a corporate system that is highly appreciated and we hope that you continue to select and use Kasin products with pride and satisfaction.
Exhibition
Certificates
Our Service
1. The questions about the coupling will be answered within 24 hours.
2. Update the procession of manufacturing.
3. Our professional engineer can answer technical questions,help you solve technical problems and help you choose the most suitable product according to your requirment.
4. Warranty 12 months: Free replacement of defective products within 12 months.
Packing Details & Delivery
Inner Packing: Carton, Standard export packing or According to customer's requirement
Outer packing: wooden cases or According to customer's requirement
FAQ
Q: Are you trading company or manufacturer ?
A: We are professionally manufacturer in China and own ourself Forging & Casting-workshop, warmly welcome to visit our factory at any time.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, it's available for Kasin to submit sample for approval free of charge, however it's Kasin regulation: for new potentioal customer, sample is free but customer is responsilble for logistic fee.
Q: What is your terms of payment ?
A: 100% T/T before shipment after cargo inspect well
******************************************************************************************************
